The foundation of RT-Tech is knowledge and response. We have extensive knowledge and experience in Oil and Gas industry. Key to our success is:

- Good Products
- Excellent service
- Cost effective solutions

Well Test, Automated Reporting RealTime Interfaces PI2CSV PI to CSV





















RT Well Test Manager:

Unlike in SCADA system where the well testing is done only in real-Time mode,  using this product you can do well testing any time you want  and select your own time period.  The product uses OsiSoft ‘s PI historian or PHD historian to retrieve raw values of test attributes.  You can select a time period, review test results and if any reason you think the well test is not good due to device error and communications problems, you can change the test period and re-run the well test.  The product has options to do Direct well testing, Well Testing by Difference or Split well testing.

It has an interface to create well tests reports for any or all wells for a given period.  The well tests can be trended for visualization.  Well test can also be edited by authorized people. You can also set test types like Good Test, Use for Allocation or Trial test and add comments.

The well test data can be easily integrated with other business applications and also can be exported to Microsoft Excel file.

Key Benefits

  • Well Testing based on Historian data, do testing anytime you want
  • Visual well test, view say rate trend graph, select well test period and create a well test.
  • Direct Testing, Test by difference, Split testing
  • View test results, ability to edit well test data by authorized people, insert comments.
  • Export to well test results to Microsoft Excel
  • Money back guarantee, customization possible to meet business needs.
  • Access to source code


Well Test, Automated Reporting RealTime Interfaces PI2CSV PI to CSV






















Interfaces:

Increase your productivity, use these loaders to load data to OsiSoft PI historian. These interfaces can do one time data load or can run as service or using scheduler

Text-to-PI:  Load data to PI from any CSV (Comma Separated file) or Text file

OLEDB-to-PI: Load data to Pi from any OLEDB compatible data base like Oracle or SQL Server

XLS-To-PI: Load data to PI from any XLS file. It creates a cross-reference between a Excel cell and PI tag and can run in an interactive one time mode or automated batch mode as service or using Scheduler.

Web-To-PI:  Load data to file by scraping values from a Web page or web service

PI-TO-CSV:  Create a CSV file for a given number of tags and Time period in an Interactive or batch mode. This could be used to transfer PI data to other systems.

Key Benefits

  • Load data with minimum effort, improve productivity.
  • If tags are already being scanned, you can still use these tools to fix ad doc issues
  • Would customize to meet your Business needs
  • Money back Guarantee
  • Availability to source code


Well Test, Automated Reporting RealTime Interfaces PI2CSV PI to CSV

Automated Reporting and Editing:

A go by sample to create automated reporting. The tools gets values from OsiSoft PI in to a form, you can view/validate raw data, save validated data to a validated tags and form report based on Excel template. Ideal for creating AM report, Chemical injection report, Operations report and any kind of report that needs scanned data from the historian (PI or PHD).

Key Benefits

  • Generate report with minimum efforts, no re-typing of scanned data.
  • All validated data saved in the historian, can be viewed or trended
  • Automatically email report and do alerting.


More:

Chemical Injection MonitoringTool

RealTime Advanced Calculation Engine

Real-Time Alerting System

Pressure Testing Tool based on Historian data

Pricing

The product can be purchased on  per computer basis or with unlimited Corporate license.
